Other Availability Stainless Steel Grades Sheets & Plates - In stock
SS 904L Plates, Stainless Steel 904L Plates, Stainless Steel 904L Sheets, Stainless Steel 904L Sheets and Plates in India.
Table Of Content
- What is Stainless Steel 904L Sheets & Plates
- Size Range and Standard Specifications for Stainless Steel 904L Sheets
- Markings On The Stainless Steel 904L Sheets & Plates
- ASTM A240 Stainless Steel Plates Equivalent Grades
- Stainless Steel 904L Sheets and Plates Forms
- Stainless Steel 904L Sheets Sizes in Stock
- Chemical Composition of Stainless Steel 904L Sheets and Plates
- Mechanical Properties of Stainless Steel 904L Sheets and Plates
- Stainless Steel 904L Plates Application Industries
- People Also Searched for
ASTM A240 SS 904L Plates, Stainless Steel 904L Cold Rolled Sheets, 904L stainless steel plate, Jindal Steel 904L Stainless Steel Hot Rolled Plates, 904L stainless steel price, SS 904L Sheets Manufacturers in India.
stainless steel 904l sheets price, stainless steel 904l sheets and plates price per kg, ss 904l sheets suppliers, stainless steel 904l plates price in Mumbai, stainless steel 904l plates cost, astm a240 stainless steel 904l plates price list in india.
Alloy 904L or UNS N08904 is a super Austenitic Stainless Steel. SS 904L is a combination of high Chromium and Nickel with additional Molybdenum and Copper. It includes 25% Nickel and 4.5% Molybdenum, which has excellent corrosion resistance. This alloy is widely used because of the property of high corrosion resistance in a wide range of process environments. It also offers resistance to stress, corrosion cracking resistance, pitting, and general corrosion. SS 904L is a lower carbon version of Austenitic Stainless Steel that is suitable for diluting sulfuric acid environments.
Seamac Piping Solutions Inc. is one of the leading manufacturers and suppliers of SS 904L products. As per the customer’s requirements, we are fabricating various products using different materials. SS 904L Sheet Plates are among the widely used products from our inventory. We supply a wide range of SS 904L Plates in various specifications to make them suitable for various industrial applications. Seamac Piping Solutions Inc. is also the best quality ASTM B625 904L Sheets and Plates supplier and exporter in India.
Seamac Piping Solutions Inc. carries a wide range of stainless steel 904l sheets and plates in a variety of lengths, ODs, IDs, size and wall thicknesses to meet your project’s needs—including sheets and plates in dimension as per ASTM and weight-kg. per mtr. weight & thickness of 904l stainless steel sheets plates .
Our high-grade SS 904L Sheet Plate has numerous beneficial features such as good formability, weldability, durability, high tensile strength, and suitable for high temperature and pressure applications. In addition, these Plates provide:
- Resistance to pitting and crevice corrosion.
- Stress corrosion cracking.
- Intergranular corrosion.
- Excellent resistance against many inorganic acids such as hot phosphoric acid and most organic acids.
Seamac Piping Solutions Inc. is a customer-focused manufacturing firm. Hence, we aim to supply perfectly suitable SS 904L Sheet Plate to our clients within the decided time and at reasonable rates. We are using modern machinery, tools, and technology. We have adopted advanced technology and defined the manufacturing process, making us able to fabricate SS 904L Sheet Plate in large numbers without compromising quality.
Stainless Steel 904L Sheets and Plates Specifications
Specification : ASTM A240 / ASME SA240
Dimension Standard : JIS, AISI, ASTM, GB, DIN, EN, etc
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Surface Finishing : Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc.
Markings On The Stainless Steel 904L Sheets & Plates
The full identification of the sheets should be continuously marked down its whole length, including :
- Rating Designation
- Material Designation
- Specification Number
- Grade
- Length
- Manufacturer's Name or Symbol
ASME SA240 Stainless Steel 904L Sheets and Plates Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | KS | AFNOR | EN |
| SS 904L | 1.4539 | N08904 | SUS 904L | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
We are manufacturing a full range of SS 904L Sheet Plate in customized as well non-customized form. With strict inspection and testing under the supervision of our skilled professionals, we deliver the most precise and dimensionally accurate SS 904L Sheet Plate to our clients. We are here to supply the highest quality Plates with a smooth and convenient doorstep service.
Stainless Steel 904L Sheets and Plates Types
SS 904L Perforated Sheets
ASTM A240 SS 904L Perforated Sheets
UNS N08904 Perforated Sheets
SS 1.4539 Perforated Sheets
SS 904L Chequered Plates
ASTM A240 TP904L Chequered Plates
UNS N08904 Chequered Plates
SS 1.4539 Chequered Plates
Stainless Steel 904L Shim Sheets
ASTM A240 SS 904L Shim Sheets
UNS N08904 Shim Sheets
SS 1.4539 Shim Sheets
Stainless Steel 904L Coils
ASTM A240 SS 904L Coils
UNS N08904 Coils
SS 1.4539 Coils
Stainless Steel 904L Sheets Sizes in Stock:
All Sheets and Plates is manufactured and tested / inspected to the relevant standards including ASTM, ASME and API etc.
| Stainless Steel Gauge Width and Length | Weight Lbs. per Sq. Ft. | Estimated Weight per Sheet |
|---|---|---|
| 7 ga. (.1874") x 48 x 120 | 7.871 | 314.8 |
| 10 ga. (.135") x 48 x 120 | 5.670 | 226.8 |
| 11 ga. (.120") x 36 x 120 | 5.040 | 151.2 |
| 11 ga. (.120") x 48 x 96 | 5.040 | 161.3 |
| 11 ga. (.120") x 48 x 120 | 5.040 | 201.6 |
| 11 ga. (.120") x 48 x 144 | 5.040 | 241.9 |
| 11 ga. (.120") x 60 x 96 | 5.040 | 252.0 |
| 12 ga. (.105") x 36 x 120 | 4.410 | 132.3 |
| 12 ga. (.105") x 48 x 120 | 4.410 | 176.4 |
| 12 ga. (.105") x 60 x 120 | 4.410 | 220.5 |
| 14 ga. (.075") x 36 x 120 | 3.150 | 94.50 |
| 14 ga. (.075") x 48 x 120 | 3.150 | 126.0 |
| 16 ga. (.060") x 36 x 120 | 2.520 | 75.60 |
| 16 ga. (.060") x 48 x 96 | 2.520 | 80.64 |
| 16 ga. (.060") x 48 x 120 | 2.520 | 100.8 |
| 16 ga. (.060") x 60 x 120 | 2.520 | 126.0 |
| 18 ga. (.048") x 36 x 120 | 2.016 | 60.48 |
| 18 ga. (.048") x 48 x 120 | 2.016 | 80.64 |
| 20 ga. (.036") x 36 x 120 | 1.512 | 45.36 |
| 20 ga. (.036") x 48 x 120 | 1.512 | 60.48 |
| 22 ga. (.030") x 36 x 120 | 1.260 | 37.80 |
| 22 ga. (.030") x 48 x 96 | 1.260 | 40.32 |
| 22 ga. (.030") x 48 x 120 | 1.260 | 50.40 |
| 24 ga. (.024") x 36 x 120 | 1.008 | 30.24 |
| 24 ga. (.024") x 48 x 120 | 1.008 | 40.32 |
| 26 ga. (.018") x 36 x 120 | .7560 | 22.68 |
| 26 ga. (.018") x 48 x 120 | .7560 | 30.24 |
| 28 ga. (.015") x 36 x 120 | .6300 | 18.90 |
Chemical Composition of Stainless Steel 904L Sheets and Plates
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu |
| SS 904L | 0.020 max | 2 max | 1.0 max | 0.040 max | 0.030 max | 19-23 | 4.00-5.00 | 23.00-28.00 | 1.00-2.00 |
Mechanical Properties of SS 904L Sheets and Plates
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.95 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35 % |
Stainless Steel 904L Sheets and Plates Application Industries
- Chemical Industry
- Petrochemical industry
- Marine & Power Transmission industry
- Power plants
- Energy industries
- Furniture
- Pharmaceutical processing industry
- Modern architecture
- Home appliances
- Water waste projects
- Synthetic fiber
- Heat exchanger
- Fluid piping
- Dairy and food processing
